UF Series Ultra-Flexible Cable Assembly
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
UF Series ultra-flexible cable assemblies (18–40 GHz) are easy to route in tight spaces and are well suited to bench testing and equipment interconnection where frequent movement is required.
Key Features
- Ultra-flexible coaxial cable, 50 Ω
- Up to 40 GHz (UF1)
- Low attenuation for its flexibility
- Assembled with customer-specified connectors and length
Model Options
| Model | Frequency | Jacket OD | Velocity | Atten. @6 GHz (dB/m) | Atten. @18 GHz (dB/m) | Atten. @40 GHz (dB/m) | Datasheet |
|---|---|---|---|---|---|---|---|
| UF1 | DC-40 GHz | 3.6 mm | 74 % | 1.33 | 2.45 | 3.05 | |
| UF2 | DC-26.5 GHz | 5 mm | 76 % | 1.03 | 1.98 | NA | |
| UF3 | DC-18 GHz | 8 mm | 76 % | 0.55 | 1.09 | NA |
Lengths and connector combinations can be customised. Please contact us for a quotation.
