TBG-2080-3S-180 Hybrid Coupler

Name: TBG-2080-3S-180 Hybrid Coupler
Brand: Talent Microwave
SKU: TBG-2080-3S-180
Price: 2586.0 HKD
Availability: InStock

$2,586.00

Key Features

Frequency(GHz) Min: 2
Frequency(GHz) Max: 8
Isolation(dB): 20
Insert. Loss(dB): 1.4
Phase Balance(°): 10
Amp Balance(dB): 0.7

$2,586.00

Download datasheet

Shop safely

Secure your shopping experience with various safe and trusted payment methods.

Shop safely with us

Talent 180°hybrid TBG-2080-3S-180 covers the range 2-8 GHz,while our complete line of hybrids cover frequency ranges up to 40 GHz. Any Talent model can be customized to suit your specific performance or package requirements at little to no extra cost. Talent is ISO-9001 registered

Key Specifications

Frequency(GHz) Min	2
Frequency(GHz) Max	8
Isolation(dB)	20
Insert. Loss(dB)	1.4
Phase Balance(°)	10
Amp Balance(dB)	0.7
VSWR	1.5
Connector	SMA
Power(W)	50
Operating Temperature	-45-+85℃
