N to SSMA Coaxial Adapter
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
The N to SSMA coaxial adapter series from Talent Microwave provides a precision 50 Ω transition between N and SSMA interfaces for test and measurement, VNA calibration, satellite communication and radar applications, covering DC to 18 GHz.
Key Features
- Between-series N to SSMA coaxial adapter, 50 Ω
- Frequency range DC to 18 GHz
- VSWR ≤ 1.1
- Available gender combinations: Male–Male, Male–Female, Female–Female
- Body styles: Straight
- Individual datasheet available for every model
Model Options
| Model | Interface 1 | Interface 2 | Frequency | VSWR (max) | Body Style | Datasheet |
|---|---|---|---|---|---|---|
| N/SSMA-JJ | N Male | SSMA Male | DC–18 GHz | 1.1 | Straight | — |
| N/SSMA-JK | N Female | SSMA Male | DC–18 GHz | 1.1 | Straight | — |
| N/SSMA-KJ | N Male | SSMA Female | DC–18 GHz | 1.1 | Straight | — |
| N/SSMA-KK | N Female | SSMA Female | DC–18 GHz | 1.1 | Straight | — |
Model codes: J = male (plug), K = female (jack). Please contact us for a quotation.
