A Series Ultra-Low-Loss Phase-Stable Cable Assembly
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
A Series ultra-low-loss flexible phase-stable cable assemblies cover 18 GHz to 110 GHz and are designed for test and measurement systems that need low insertion loss with excellent phase stability versus flexure and temperature.
Key Features
- Ultra-low-loss phase-stable flexible cable, 50 Ω
- Up to 110 GHz (A15)
- Mechanical phase stability ±3° to ±4° @ 18 GHz
- Phase change vs. temperature ≤ 550 ppm
- Assembled with customer-specified connectors and length
Model Options
| Model | Frequency | Jacket OD | Velocity | Mech. Phase @18 GHz | Atten. @6 GHz (dB/m) | Atten. @18 GHz (dB/m) | Atten. @40 GHz (dB/m) | Datasheet |
|---|---|---|---|---|---|---|---|---|
| A15 | DC-110 GHz | 1.54 mm | 80 % | ±3° | 2.82 | 4.99 | 7.6 | |
| A22 | DC-67 GHz | 2.2 mm | 82 % | ±3° | 1.61 | 2.87 | 4.44 | |
| A40 | DC-40 GHz | 3.6 mm | 82 % | ±3° | 0.93 | 1.66 | 2.56 | |
| A48 | DC-26.5 GHz | 4.8 mm | 83 % | ±3.5° | 0.59 | 1.06 | NA | |
| A50 | DC-26.5 GHz | 5.1 mm | 83 % | ±3.5° | 0.57 | 1.01 | NA | |
| A75 | DC-18 GHz | 7.5 mm | 83 % | ±4° | 0.38 | 0.67 | NA | |
| A81 | DC-18 GHz | 7.8 mm | 83 % | ±4° | 0.37 | 0.67 | NA | |
| A120 | DC-8 GHz | 12 mm | 83 % | ±4° | 0.26 | NA | NA |
Lengths and connector combinations can be customised. Please contact us for a quotation.
