2.92mm to SSMP Coaxial Adapter
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
The 2.92mm to SSMP coaxial adapter series from Talent Microwave provides a precision 50 Ω transition between 2.92mm and SSMP interfaces for test and measurement, VNA calibration, satellite communication and radar applications, covering DC to 40 GHz.
Key Features
- Between-series 2.92mm to SSMP coaxial adapter, 50 Ω
- Frequency range DC to 40 GHz
- VSWR ≤ 1.25
- Available gender combinations: Male–Male, Male–Female, Female–Female
- Body styles: Straight
- Individual datasheet available for every model
Model Options
| Model | Interface 1 | Interface 2 | Frequency | VSWR (max) | Body Style | Datasheet |
|---|---|---|---|---|---|---|
| 2.92/SSMP-JJG | 2.92mm Male | SSMP Male | DC–40 GHz | 1.25 | Straight | |
| 2.92/SSMP-JKG | 2.92mm Male | SSMP Female | DC–40 GHz | 1.25 | Straight | |
| 2.92/SSMP-KJG | 2.92mm Female | SSMP Male | DC–40 GHz | 1.25 | Straight | |
| 2.92/SSMP-KKG | 2.92mm Female | SSMP Female | DC–40 GHz | 1.25 | Straight |
Model codes: J = male (plug), K = female (jack). Please contact us for a quotation.
