2.92mm to 3.5mm Coaxial Adapter
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
The 2.92mm to 3.5mm coaxial adapter series from Talent Microwave provides a precision 50 Ω transition between 2.92mm and 3.5mm interfaces for test and measurement, VNA calibration, satellite communication and radar applications, covering DC to 26.5 GHz.
Key Features
- Between-series 2.92mm to 3.5mm coaxial adapter, 50 Ω
- Frequency range DC to 26.5 GHz
- VSWR ≤ 1.15
- Available gender combinations: Male–Male, Male–Female, Female–Female
- Body styles: Straight
- Individual datasheet available for every model
Model Options
| Model | Interface 1 | Interface 2 | Frequency | VSWR (max) | Body Style | Datasheet |
|---|---|---|---|---|---|---|
| 3.5/2.92-JJ | 2.92mm Male | 3.5mm Male | DC–26.5 GHz | 1.15 | Straight | |
| 3.5/2.92-JK | 2.92mm Female | 3.5mm Male | DC–26.5 GHz | 1.15 | Straight | |
| 3.5/2.92-KJ | 2.92mm Male | 3.5mm Female | DC–26.5 GHz | 1.15 | Straight | |
| 3.5/2.92-KK | 2.92mm Female | 3.5mm Female | DC–26.5 GHz | 1.15 | Straight |
Model codes: J = male (plug), K = female (jack). Please contact us for a quotation.
