2.4mm to 3.5mm Coaxial Adapter
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
The 2.4mm to 3.5mm coaxial adapter series from Talent Microwave provides a precision 50 Ω transition between 2.4mm and 3.5mm interfaces for test and measurement, VNA calibration, satellite communication and radar applications, covering DC to 33 GHz.
Key Features
- Between-series 2.4mm to 3.5mm coaxial adapter, 50 Ω
- Frequency range DC to 33 GHz
- VSWR 1.15 to 1.25 (model dependent)
- Available gender combinations: Male–Male, Male–Female, Female–Female
- Body styles: Straight
- Individual datasheet available for every model
Model Options
| Model | Interface 1 | Interface 2 | Frequency | VSWR (max) | Body Style | Datasheet |
|---|---|---|---|---|---|---|
| 3.5-2.4-JJ | 2.4mm Male | 3.5mm Male | DC–26.5 GHz | 1.15 | Straight | |
| 3.5-2.4-JKG | 2.4mm Female | 3.5mm Male | DC–26.5 GHz | 1.15 | Straight | |
| 3.5-2.4-KJ | 2.4mm Male | 3.5mm Female | DC–26.5 GHz | 1.15 | Straight | |
| 3.5-2.4-KKG | 2.4mm Female | 3.5mm Female | DC–33 GHz | 1.25 | Straight |
Model codes: J = male (plug), K = female (jack). Please contact us for a quotation.
