1.35mm to 1.35mm Coaxial Adapter
Interested in this product?
Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.
The 1.35mm to 1.35mm coaxial adapter series from Talent Microwave provides a precision 50 Ω transition between two 1.35mm interfaces for test and measurement, VNA calibration, satellite communication and radar applications, covering DC to 90 GHz.
Key Features
- In-series 1.35mm coaxial adapter, 50 Ω
- Frequency range DC to 90 GHz
- VSWR ≤ 1.4
- Available gender combinations: Male–Female, Female–Female
- Body styles: Straight
- Individual datasheet available for every model
Model Options
| Model | Interface 1 | Interface 2 | Frequency | VSWR (max) | Body Style | Datasheet |
|---|---|---|---|---|---|---|
| 1.35-JK | 1.35mm Male | 1.35mm Female | DC–90 GHz | 1.4 | Straight | |
| 1.35-KK | 1.35mm Female | 1.35mm Female | DC–90 GHz | 1.4 | Straight |
Model codes: J = male (plug), K = female (jack). Please contact us for a quotation.
