TLPA2G6G-40-15-GCR20 is a gain control amplifier with a minimum small signal gain of 40 dB and a minimuml P1dB of 15 dBm @no gain control across the frequency range of 2 to 6 GHz. The DC power requirement for the amplifier is +12VDC/360 mA. The input and output port configuration offers coax adapter structure with SMA female.
Key Specifications
| Frequency(GHz) Min | 2 |
|---|---|
| Frequency(GHz) Max | 6 |
| Gain (dB) | 40 |
| Gain flatness (± dB) | 2.25 |
| P1dB(dBm) | 15 |
| VSWR | 2 |
| Connector | SMA |
Available from NP LAB / Nanopico Lab, Hong Kong. Lead times typically follow Talent Microwave stock status; contact us for current availability.
Official product page: TLPA2G6G-40-15-GCR20
