TLPA1G12G-24-26-H is a power amplifier with a typical small signal gain of 24 dB and a nominal Psat of 26 dBm across the frequency range of 1 to 12 GHz. The DC power requirement for the amplifier is +12 VDC/420 mA. The input and output port configuration offers coax adapter structure with SMA female.
Key Specifications
| Frequency(GHz) Min | 1 |
|---|---|
| Frequency(GHz) Max | 12 |
| Gain (dB) | 24 |
| P1dB(dBm) | 25 |
| Psat(dBm) | 26 |
| VSWR | 2 |
| Connector | SMA |
Available from NP LAB / Nanopico Lab, Hong Kong. Lead times typically follow Talent Microwave stock status; contact us for current availability.
Official product page: TLPA1G12G-24-26-H
