SSG5083A 9kHz~13.6GHz +23dBm

Frequency up to 13.6 GHz

0.001 Hz frequency setting resolution

Level setting range: -130 dBm ~ +25 dBm

Phase Noise: -120 dBc / Hz @ 1 GHz, 20 kHz offset (typ.)

Level error ≤ 0.7 dB (typ.)

Provides AM, FM, PM analog modulation with internal, external or Int+Ext source

Single pulse, double pulse and pulse train generator (opt.)
