Input Channels
4 or 6 FlexChannel inputs
Each FlexChannel provides 1 analog signal input or 8 digital logic inputs with TLP058 probe

Bandwidth
200 MHz, 350 MHz, 500 MHz, 1 GHz or 1.5 GHz

Sample Rate
6.25 GS/s on all analog/digital channels

Record Length
31.25 or 62.5 Mpoints

Vertical Resolution
12 bits
Up to 16 bits in High Res mode

Signal Generation
Arbitrary, Sine, Square, Pulse, Ramp, Triangle, DC Level, Gaussian, Lorentz, Exponential Rise/Fall, Sin(x)/x, Random Noise, Haversine, Cardiac

Digital Voltmeter
4-digit AC RMS, DC
DC+AC RMS voltage

Trigger Frequency Counter
8-digit

Advanced Analysis
Spectrum View Mixed Domain Analysis
Automated Power Measurements
3-Phase Power Measurements

Protocol Support
10BASE-T, 100BASE-TX, 10BASE-T1S
CAN, CAN FD, LIN, FlexRay
I²C, SPI
MIL-STD-1553, ARINC 429
RS-232, RS-422, RS-485, UART
SPMI
SVID
USB 2.0 LS, FS, HS

Display
13.3-inch (338 mm)
HD color (1920 x 1080) capacitive touchscreen

Dimensions (H x W x D)
287 mm x 405 mm x 155 mm
(11.3 in x 15.9 in x 6.1 in)

Weight
16 lbs (7.3 kg)
