3140B BiConiLog Antenna

Product Features

Frequency range: 26 MHz – 3 GHz
Two Year Warranty
Fits Compact Chambers
Tough Powder Coat Finish
Avg. 2:1 VSWR above 80 MHz
Best EMC RI Performance from 26 MHz to 80 MHz ≤ 300 W to generate 10 V/m above 30 MHz at 3m, 80% AM
Official ETS-Lindgren product
Enquire for quotation and configuration

Download datasheet

Interested in this product?

Send us your details and we’ll get back to you with availability, pricing, and any additional information you need.

3140B BiConiLog Antenna

The Model 3140B BiConiLog Antenna is one in a series of antennas designed for broadband EMC radiated immunity (RI) measurements. It is composed of a patented T-Bow Tie element design that significantly improves low frequency performance, compared to conventional biconical or other hybrid antennas. These T-Bow Tie elements are easily attached/detached with hand tightened screw knobs, and the antenna is self-standing when placed balun end down on a ground plane.

Note: The Model 3140B BiConiLog is not designed to be used for RE (radiated emissions) measurements.

Key Features

Frequency Range: 26 MHz – 3 GHz
Two Year Warranty
Fits Compact Chambers
Tough Powder Coat Finish
Avg. 2:1 VSWR above 80 MHz
Best EMC RI Performance from 26 MHz to 80 MHz ≤ 300 W to generate 10 V/m above 30 MHz at 3m, 80% AM
