Key Features

• Five instruments in one (IV Source, IVR Measure)
• Three models: 20 W, 1100 V to 1 µV, 1 A to 10 pA
• Source and sink (4-quadrant) operation
• 0.012% basic measure accuracy with 6½-digit resolution
• 2-, 4-, and 6-wire remote V-source and measure sensing
• 1700 readings/second at 4½ digits via GPIB
• Pass/Fail comparator for fast sorting/binning
• Programmable DIO port for automation/handler/prober control (except 2401)
• Standard SCPI GPIB, RS-232 and Keithley Trigger Link interfaces
• Download KickStart today and try it out for 30 days
